Description
Looking for a flexible, accurate power distribution solution that allows metering and switching at the outlet level and supports both local and remote power management? The HPE G2 Metered and Switched Power Distribution Unit (PDU) provides both local and remote power management with outlet-level power metering and switching. An LCD screen provides local monitoring and alert indications, while remote access and configuration are available through secure Web, SNMP, CLI, or Telnet interfaces. Remote outlet monitoring offers ±1% billing grade accuracy while remote switching capabilities support power on/off functionality to remotely reboot equipment or restrict outlet usage. The G2 Metered and Switched PDU features a low-profile, single-piece design with multiple mounting options and ease of access to rear devices for maintenance. It is compatible with all Advanced and Enterprise Series Racks, as well as with many non-HPE racks using standard button and keyhole mounting.
What is new supporting point:
HPE G2 Metered and Switched Power Distribution Units (PDU) are rated for operating temperatures of up to 60°C (or 140°F).
Color-coded receptacles on single and three phase models to easily distinguish between the different load segments/phases.
A hot swappable Network Management Card (NMC) allowing for power to remain distributed with the removal of the management card thus creating zero down time.
Enhanced environmental sensor options on the G2 Metered and Switched PDUs for monitoring temperature, humidity, intrusion, and water leakage within the rack.
Choose the optional Locking Power Cord for secure cable retention to both the PDU and target device.
Specifications
Weight & dimensions | |
---|---|
Weight | 16.7 kg |
Height | 132.1 mm |
Depth | 1979.9 mm |
Width | 261.9 mm |
Power | |
Load capacity | 10000 VA |
Maximum current | 48 A |
Nominal input voltage | 208 V |
Ports & interfaces | |
AC outlet types | C19 coupler |
Design | |
Mounting | Vertical |
Rack capacity | 0U |
Type | Three-phase |
PDU types | Metered, Switched |
