625609-B21 HPE 1TB SATA 3G 7.2K SFF 2.5in Hot Plug Midline HDD - G4-G7
- HP 1TB 3G SATA 7.2K rpm SFF (2.5-inch) Hot Plug Midline Hard Drive
- Photos are indicative and may differ. SpareIT tries to represent this as correctly as possible.
Disclaimer:
Product photos and specifications are made available by Universal Databases and are often based on new products.
When the item is a 'Refurbished product' it has been tested by us and has an A-grade condition (unless otherwise stated). Refurbished items do not include cables, software media and manuals (unless otherwise stated).
Please read the product description carefully and contact us if you have any questions.
Description
Option Part Number: 625609-B21
Spare Part Number: 626162-001
Model Number: MM1000EBKAF
Assembly Number: 614828-003
HPE GPN: 390158-022
General
Device Type: Hard Drive - Internal
HDD Capacity: 1 TB
Form Factor: 2.5 inch SFF
Interface: SATA-3Gbps
External Data Transfer Rate: 300 MBps
Spindle Speed: 7200 RPM
Carrier Type: Standard Carrier
Workload Type: Midline
Buffer: 64 MB
Bundled With: HPE Standard Carrier
Performance
Seek Time: 8.5 ms (average) / 16.96 ms (max)
Track-to-Track Seek Time: 0.7 ms
Expansion & Connectivity
Interfaces: 1 x SATA 3 Gb/s
Compatible Bays: 2.5" SFF
Environmental Parameters
Min Operating Temperature: 50 °F
Max Operating Temperature: 95 °F
Compatibility Information
Designed For
HPE ProLiant BL Series: BL20p (Gen4) BL45p (Gen2) BL460c (Gen6 Gen7) BL465c (Gen1 Gen5 Gen6 Gen7) BL480c (BL620c Gen7) BL680c (Gen5 Gen6 Gen7) BL685c (Gen6 Gen7) WS460c (Gen6 Gen7)
HPE ProLiant DL Series: DL100 (Gen6 Gen7) DL120 (Gen6 Gen7) DL160 (Gen6 Gen7) DL160se (Gen6 Gen7) DL165 (Gen6 Gen7) DL170e (Gen6 Gen7) DL170h (Gen6 Gen7) DL180 (Gen6 Gen7) DL320 (Gen6 Gen7) DL360 (Gen4p Gen5 Gen6 Gen7) DL365 (Gen1 Gen5 Gen6 Gen7) DL370 (Gen6 Gen7) DL380 (Gen4 Gen5 Gen6 Gen7) DL385 (Gen1 Gen2 Gen3 Gen4 Gen5/Gen5p Gen6 Gen7) DL580 (Gen3 Gen4 Gen5 Gen6 Gen7) DL585 (Gen2 Gen3 Gen4 Gen6 Gen7) DL785 (Gen6)
HPE ProLiant ML Series: ML110 (Gen7) ML350 (Gen5 Gen6 Gen7) ML370 (Gen5 Gen6 Gen7) ML570 (Gen3 Gen4 Gen5)
HPE ProLiant SL Series: SL390s (Gen6 Gen7)
HPE ProLiant WS Series: WS460c (Gen6 Gen7)
HPE Storage Arrays: D2700 MSA 1040 MSA70 P2000 (Gen3) X1500 (Gen2) X16000 (Gen2) X1800 (Gen2) X3400 (Gen2) X3800 (Gen2) 2000i (Gen2) 2000sa (Gen2)
Specifications
| Weight & dimensions | |
|---|---|
| Weight | 1.36 kg |
| Height | 16 mm |
| Depth | 136.6 mm |
| Width | 72.2 mm |
| Power | |
| Operating voltage | 5 V |
| Features | |
| Average seek time | 8.5 ms |
| Hard drive | |
| Bytes per sector | 512 |
| HDD interface transfer rate | 3 Gbit/s |
| Track to track seek time (read/write) | 0.7 ms |
| Full stroke seek | 16.96 ms |
| HDD form factor | 2.5" |
| HDD speed | 7200 RPM |
| Type | HDD |
| HDD interface | Serial ATA |
| HDD capacity | 1 TB |
