HPE Aruba Networking AP-377 (US) 1733 Mbit/s White Power over Ethernet (PoE)
- Aruba AP-377 (US) 802.11n/ac Dual 2x2:2/4x4:4 Radio Integrated Directional Antenna Outdoor AP
- Photos are indicative and may differ. SpareIT tries to represent this as correctly as possible.
Disclaimer:
Product photos and specifications are made available by Universal Databases and are often based on new products.
When the item is a 'Refurbished product' it has been tested by us and has an A-grade condition (unless otherwise stated). Refurbished items do not include cables, software media and manuals (unless otherwise stated).
Please read the product description carefully and contact us if you have any questions.
Description
Weatherproof and temperature hardened, Aruba 370 series access points deliver 802.11ac Wave 2 Gigabit Wi-Fi to outdoor and environmentally challenging locations.
Delivers 4x4:4SS MU-MIMO capability, Aruba’s advanced ClientMatch and an integrated Bluetooth beacon to enable Aruba location services. Also for improved network simplicity and security, Dynamic Segmentation automatically enforces real-time device-level access policies on Aruba wired and wireless networks.
Specifications
| Weight & dimensions | |
|---|---|
| Weight | 2.1 kg |
| Weight | 2.1 kg |
| Height | 130 mm |
| Height | 130 mm |
| Depth | 220 mm |
| Depth | 220 mm |
| Width | 230 mm |
| Width | 230 mm |
| Operational conditions | |
| Operating altitude | 0 - 3000 m |
| Operating altitude | 0 - 3000 m |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | -40 - 65 °C |
| Operating temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating relative humidity (H-H) | 5 - 95% |
| Algemeen | |
| Productfamilie | Aruba Networking |
| Productfamilie | Aruba Networking |
| Features | |
| Maximum data transfer rate (5 GHz) | 1733 Mbit/s |
| Maximum data transfer rate (5 GHz) | 1733 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 300 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 300 Mbit/s |
| Design | |
| Product colour | White |
| Product colour | White |
| Placement | Wall |
| Placement | Wall |
| Cable lock slot | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Cable lock slot type | Kensington |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| AC input frequency | 50 - 60 Hz |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) | Yes |
| Antenna | |
| Antenna gain level (max) | 34.4 dBi |
| Antenna gain level (max) | 34.4 dBi |
| Antennas quantity | 4 |
| Antennas quantity | 4 |
| Antenna type | Internal |
| Antenna type | Internal |
| Antenna direction type | Omni-directional |
| Antenna direction type | Omni-directional |
| Ports & interfaces | |
| USB 2.0 ports quantity | 1 |
| USB 2.0 ports quantity | 1 |
| USB connector type | Mini-USB |
| USB connector type | Mini-USB |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Performance | |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az |
| Channel bandwidth | 160 MHz |
| Channel bandwidth | 160 MHz |
| Modulation | 16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK |
| Modulation | 16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK |
| Quality of Service (QoS) support | Yes |
| Quality of Service (QoS) support | Yes |
| Auto MDI/MDI-X | Yes |
| Auto MDI/MDI-X | Yes |
| MIMO | Yes |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| MIMO type | Multi User MIMO |
| Number of users | 256 user(s) |
| Number of users | 256 user(s) |
| 5 GHz | Yes |
| 5 GHz | Yes |
| 2.4 GHz | Yes |
| 2.4 GHz | Yes |
| Spread spectrum method | DSSS, OFDM |
| Spread spectrum method | DSSS, OFDM |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Data transfer rate (max) | 1733 Mbit/s |
| Data transfer rate (max) | 1733 Mbit/s |
