JL587A HP FlexFabric 5710 24SFP+ 6QS+/2QS28 24 Ports Switch
- HPE Networking Comware Switch 24SFP+ 6QSFP+ or 2QSFP28 5710
- Managed
- L3
- Rack mounting
- 1U
- Photos are indicative and may differ. SpareIT tries to represent this as correctly as possible.
Disclaimer:
Product photos and specifications are made available by Universal Databases and are often based on new products.
When the item is a 'Refurbished product' it has been tested by us and has an A-grade condition (unless otherwise stated). Refurbished items do not include cables, software media and manuals (unless otherwise stated).
Please read the product description carefully and contact us if you have any questions.
Description
The HPE Networking Comware Switch Series 5710 are purpose built top-of-rack data center switches that address the growth of Web, cloud and dense virtualized environments that require high performance 1/10GbE server connectivity, direct attached IP storage networking and GbE out-of-band server management. The 5710 Series switch is a family of fixed high-performance and low-latency 1/10GbE top-of-rack data center switches designed for small to mid-size data center rack server connectivity. The HPE Networking Comware Switch Series 5710 provides choices that fit your budget and IT environment by offering different port density and speeds (1/10G) SFP+ or 10BASE-T with 40 and 100GbE high speed uplinks options. Although affordability priced, the 5710 Series switch offers a comprehensive set of data center features including full support for Layer 2, Layer 3, IPv4 and IPv6 networking protocols at no additional cost for these advanced features.
What is new supporting point:
Delivers up to 1,440 Gbps switching capacity for the most demanding applications.
Low latency, under 1.5 µs 10GbE latency, provides improved throughput and fewer lost packets.
Provides choices that fit your budget and IT environment by offering different port density and speeds (1/10G) SFP+ or 10BASE-T with 40 and 100GbE high speed uplinks options.
Affordably priced, with full support for Layer 2, Layer 3, IPv4 and IPv6 networking protocols at no additional cost for these advanced features.
New made in USA TAA-compliant SKUs offer heightened security via manual and automated source code analysis to address common programming issues, easing concerns about "made in China" products
Specifications
| Weight & dimensions | |
|---|---|
| Weight | 8.55 kg |
| Height | 44 mm |
| Depth | 400 mm |
| Width | 440 mm |
| Operational conditions | |
| Heat dissipation | 457 BTU/h |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 45 °C |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Power | |
| Redundant power supply (RPS) support | Yes |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Power supply included | Yes |
| Performance | |
| Harmonized System (HS) code | 85176990 |
| Flash memory | 1024 MB |
| Packet buffer memory | 12 MB |
| Memory type | SDRAM |
| Internal memory | 4096 MB |
| Virtual stacking (units) | 10 |
| Physical stacking (units) | 9 |
| Design | |
| Product colour | Black |
| Form factor | 1U |
| Stackable | Yes |
| Rack mounting | Yes |
| Protocols | |
| IPv6 FIB entries | 8000 |
| IPv4 FIB entries | 16000 |
| Routing protocols | BGP, IP, MPLS, OSPF, RIP, VRRP |
| Security | |
| Access Control List (ACL) | Yes |
| Authentication type | IEEE 802.1x, RADIUS |
| DHCP features | DHCP client, DHCP server |
| Data transmission | |
| Jumbo frames support | Yes |
| Latency (10 Gbps) | 1.5 µs |
| Throughput | 714 Mpps |
| Switching capacity | 960 Gbit/s |
| MAC address table | 208000 entries |
| Networking | |
| 10G support | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| Spanning tree protocol | Yes |
| Networking standards | IEEE 802.1D, IEEE 802.1Qau, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1ab, IEEE 802.1ag, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ah |
| Ports & interfaces | |
| SFP+ module slots quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | No |
| Basic switching RJ-45 Ethernet ports quantity | 0 |
| Management features | |
| Quality of Service (QoS) support | Yes |
| Switch layer | L3 |
| Switch type | Managed |
