HPE ProLiant DL360 Gen10 Plus 4314 2.4GHz 16-core 1P 32GB-R MR416i-a NC 8SFF 800W PS EU Server
- ProLiant DL360 Gen10 Plus 4314 2.4GHz 16-core 1P 32GB-R MR416i-a NC 8SFF 800W PS EU Server
- Photos are indicative and may differ. SpareIT tries to represent this as correctly as possible.
Disclaimer:
Product photos and specifications are made available by Universal Databases and are often based on new products.
When the item is a 'Refurbished product' it has been tested by us and has an A-grade condition (unless otherwise stated). Refurbished items do not include cables, software media and manuals (unless otherwise stated).
Please read the product description carefully and contact us if you have any questions.
Description
Do you need to efficiently expand or refresh your IT infrastructure to propel the business? Adaptable for diverse workloads and environments, the compact 1U HPE ProLiant DL360 Gen10 Plus server delivers enhanced performance with the right balance of expandability and density. Designed for supreme versatility and resiliency while backed by a comprehensive warranty, the HPE ProLiant DL360 Gen10 Plus server is ideal for IT infrastructure, either physical, virtual, or containerized. Powered by 3rd Generation Intel Xeon Scalable Processors, delivering up to 40 cores, 3200 MT/s memory, and introducing PCIe Gen4 and Intel Software Guard Extension (SGX) support to the dual-socket segment, the HPE ProLiant DL360 Gen10 Plus server delivers premium compute, memory, I/O, and security capabilities for customers focused on performance at any cost.
What is new supporting point:
Slot-less HW RAID protected M.2 boot solution, providing peace-of-mind O/S deployment while saving invaluable slots and storage bays.
Choice of storage backplanes and cages, offering diverse bay counts, protocols, and bandwidth that enable customers to design their server storage for their precise needs.
Support for industry-standard OCP 3.0 Network Adapters, enhancing customer choice.
Enhanced storage capabilities with Tri-mode controllers supporting NVMe/SAS/SATA drives, allowing customers to select the ideal media type and mix for their exact application.
64 PCIe Gen4 lanes, resulting in more devices, improved bandwidth and augmented balanced I/O capabilities.
Supports 3rd Generation Intel Xeon Scalable Processors for enhanced compute performance.
Specifications
| Weight & dimensions | |
|---|---|
| Depth | 769.6 mm |
| Height | 42.9 mm |
| Width | 434.6 mm |
| Algemeen | |
| Productfamilie | ProLiant |
| Serie producten | DL |
| Power | |
| Power supply | 800 W |
| Redundant power supply (RPS) support | Yes |
| Software | |
| Compatible operating systems | Windows Server 2016: Essentials, Standard, DatacenterWindows Server 2019: Essentials, Standard, DatacenterWindows Server 2022: Essentials, Standard, DatacenterMicrosoft Hyper-V Server: 2016, 2019 & 2022VMware vSphere: 6.7 U3 w /P03, 7.0 U2Red Hat Enterprise Linux (RHEL): 7.9, 8.2 (64 bit, includes KVM)SUSE Linux Enterprise Server (SLES): 12 SP5, 15 SP2 (64 bit, includes KVM & Xen) Canonical Ubuntu: 20.04 LTS (64 bit)Oracle Linux: 7.9, 8.2Citrix: Hypervisor: 8.2 LTSR |
| Operating system installed | No |
| Performance | |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Remote administration | iLO 5 ASIC |
| Design | |
| Optical drive type | No |
| Rack mounting | Yes |
| Chassis type | Rack (1U) |
| Ports & interfaces | |
| VGA (D-Sub) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 5 |
| Networking | |
| Ethernet LAN | Yes |
| Ethernet interface type | 10 Gigabit Ethernet |
| LAN controller | Broadcom 57416 |
| Graphics | |
| On-board graphics adapter | Yes |
| Maximum graphics adapter memory | 16 MB |
| Storage | |
| Maximum storage capacity | 24 TB |
| Hot-Plug support | Yes |
| Number of hard drives supported | 8 |
| Supported hard disk drive sizes | 2.5" |
| RAID levels | 0, 1, 5, 6, 10, 50, 60 |
| RAID support | Yes |
| Hard drive interface | SATA, Serial Attached SCSI (SAS) |
| Total storage capacity | 0 GB |
| Memory | |
| Memory slots | 32x DIMM |
| ECC | Yes |
| Memory clock speed | 3200 MHz |
| Memory layout (slots x size) | 1 x 32 GB |
| Memory ranking | 2 |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 2.05 TB |
| Internal memory | 32 GB |
| Processor | |
| Maximum number of SMP processors | 2 |
| Motherboard chipset | Intel® C621 |
| Processor boost frequency | 3.4 GHz |
| Processor manufacturer | Intel |
| Processor cache | 24 MB |
| Number of processors installed | 1 |
| Processor cores | 16 |
| Processor model | 4314 |
| Processor generation | 3rd Generation Intel® Xeon® Scalable |
| Processor family | Intel Xeon Silver |
| Processor frequency | 2.4 GHz |
