Description
Specifications
Technical details | |
---|---|
Sustainability certificates | ENERGY STAR |
Weight & dimensions | |
Depth | 730.2 mm |
Height | 97.3 mm |
Weight | 14.9 kg |
Width | 445.4 mm |
Algemeen | |
Productfamilie | ProLiant |
Serie producten | DL |
Power | |
Number of redundant power supplies installed | 2 |
Number of redundant power supplies supported | 2 |
Power supply | 800 W |
Redundant power supply (RPS) support | Yes |
Software | |
Compatible operating systems | Windows Server 2012 R2Windows Server 2016VMware ESXi 6.5 & U1Red Hat Enterprise Linux (RHEL) 7.4SUSE Linux Enterprise Server (SLES) 12 SP3 |
Operating system installed | No |
Design | |
Optical drive type | DVD-RW |
Rack mounting | Yes |
Redundant fans support | Yes |
Product colour | Black, Silver |
Chassis type | Rack (2U) |
Ports & interfaces | |
VGA (D-Sub) ports quantity | 0 |
Ethernet LAN (RJ-45) ports | 4 |
Serial ports quantity | 0 |
USB 3.0 (3.1 Gen 1) Type-A ports quantity | 5 |
USB 2.0 ports quantity | 0 |
Networking | |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
LAN controller | HP 331i |
Storage | |
Maximum storage capacity | 72 TB |
Hot-Plug support | Yes |
Number of hard drives supported | 24 |
RAID levels | 0, 1, 5, 6, 10, 50, 60 |
RAID support | Yes |
Hard drive interface | Serial Attached SCSI (SAS) |
HDD form factor | 2.5" |
Total storage capacity | 0 GB |
Number of HDDs installed | 0 |
Memory | |
Memory slots | 32x DIMM |
ECC | Yes |
Memory clock speed | 2666 MHz |
Memory layout (slots x size) | 2 x 32 GB |
Internal memory type | DDR4-SDRAM |
Maximum internal memory | 1.02 TB |
Internal memory | 64 GB |
Processor | |
Maximum number of SMP processors | 2 |
Processor boost frequency | 3.2 GHz |
Processor threads | 48 |
Processor manufacturer | AMD |
Processor cache | 64 MB |
Processor cache type | L3 |
Number of processors installed | 2 |
Processor cores | 24 |
Processor model | 7451 |
Processor family | AMD EPYC |
Processor frequency | 2.3 GHz |
