HPE BLc7000 Rack Black, Grey 2400 W
- 10 Active Cool 200 Fans
- 8 Full Height Blades/16 Half-Height Blades
- 1 Phase
- 6 Power Supplies
- ROHS
- 16 Insight Control Licenses
- Photos are indicative and may differ. SpareIT tries to represent this as correctly as possible.
Disclaimer:
Product photos and specifications are made available by Universal Databases and are often based on new products.
When the item is a 'Refurbished product' it has been tested by us and has an A-grade condition (unless otherwise stated). Refurbished items do not include cables, software media and manuals (unless otherwise stated).
Please read the product description carefully and contact us if you have any questions.
Description
The BladeSystem c7000 enclosure provides all the power, cooling, and I/O infrastructure needed to support modular server, interconnect, and storage components today and throughout the next several years. The enclosure is 10U high and holds up to 16 server and/or storage blades plus optional redundant network and storage interconnect modules.
It includes a shared 7.1 Tbps high-speed NonStop mid-plane for wire-once connectivity of server blades to network and shared storage. Power is delivered through a pooled-power backplane, and power input flexibility is provided with choices of single-phase, 3-Phase AC input, and -48V DC input.
Extending the foundation for Converged Infrastructure
The HP BladeSystem c7000 Enclosure goes beyond just Blade servers. It consolidates server, storage, networking and power management into a single solution that can be managed as a unified environment.
With demanding workloads, the increased power supply wattage and mid-plane bandwidth aligned with Intelligent Infrastructure technologies such as Platinum Power Supplies, Intelligent Power Module, and Location Discovery Services have enhanced the foundation for converged infrastructure.
HP OneView combines server, storage, and networking with control of your data center environment into a single, integrated management platform architected to deliver lifecycle management for the complete Converged Infrastructure.
With Onboard Administrator, iLO remote management, and HP Insight Control you can manage your servers and take complete control regardless of the state of the server operating system.
Specifications
| Packaging data | |
|---|---|
| Package height | 759 mm |
| Package height | 759 mm |
| Package depth | 1013 mm |
| Package depth | 1013 mm |
| Package width | 607 mm |
| Package width | 607 mm |
| Operational conditions | |
| Operating temperature (T-T) | 10 - 35 °C |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Weight | 136.1 kg |
| Weight | 136.1 kg |
| Height | 1012.9 mm |
| Height | 1012.9 mm |
| Depth | 606.5 mm |
| Depth | 606.5 mm |
| Width | 758.9 mm |
| Width | 758.9 mm |
| Power supply | |
| Power supply | 2400 W |
| Power supply | 2400 W |
| Power supply included | Yes |
| Power supply included | Yes |
| Design | |
| Rack mounting | Yes |
| Rack mounting | Yes |
| Rack capacity | 6U |
| Rack capacity | 6U |
| Product colour | Black, Grey |
| Product colour | Black, Grey |
| Type | Server |
| Type | Server |
| Form factor | Rack |
| Form factor | Rack |
